solar panel system power dc to ac 2kva pv solar power inverter for solar panel

FOB Reference Price:Get Latest Price
US $300-800 / Piece | 1 Piece/Pieces (Min. Order)
Supply Ability:
3000 Piece/Pieces per Month
Shanghai Port for solar panel system power dc to ac 2kva pv solar power inverter for solar panel
Report Suspicious Activity
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
Model Number:
Solarwii Light 0.7-3K
Output Voltage (V):
Load Power (W):
Solar Power (W):
Work Time (h):
24 Hours
Start-up DC input voltage(V):
MPPT operating range(V):
Rated AC grid voltage(V):
Grid current THD:
DC injection current(mA):
Rated grid frequency(Hz):
Operating range utility frequency(Hz):
47-52Hz or 57-62Hz(adjustable)
MPPT efficiency:
Running temperature:
-25℃ ~ 60℃
Packaging & Delivery
Packaging Details
Well protected carton with pallet for solar panel system power dc to ac 2kva pv solar power inverter for solar panel
Delivery Time
10 working days after payment

Solar panel system power dc to ac 2kva pv solar power inverter for solar panel

Product Description



Products Information


  • Compact and lightweight, visually pleasing for domestic enviroment
  • 50V-400V input voltage range-ultra low startup
  • Over 96.7% Max.efficiency
  • Precise MPPT algorithm
  • IP65 rated for external installation
  • RS485,WiFi/GPRS(optional)interface
  • Multiple protections levels
  • WiFi monitoring available-iphone and android app available
  • 5 years standrad warranty, 10 years optional upgrade



Energy SourcePV
Input Side(DC)
Max. input power(KW)0.9kW1.2kW1.8kW2.4kW3kW
Max. DC input voltage(V)450V450V450V500V500V
Start-up DC  input voltage(V)60V
MPPT operating range(V)50-400V
Max. DC input current(A)10A
Number of MPPT/Max strings per MPPT1/1
Output Side(AC)
Rated output power(KW)0.7kW1kW1.5kW2kW2.5kW
Max. transient power(KW)0.8kW1.1kW1.65kW2.2kW2.5kW
Rated AC grid voltage(V)220/230/240V
AC grid voltage range(A)180~270V(adjustable)
Operating phaseSingle
Max. AC output current(A)4.4A6.1A9.2A12.2A13.9A
Reactive Power Control settings0.8 leading…0.8 lagging
Grid current THD<3%
DC injection current(mA)<20mA
Rated grid frequency(Hz)50/60Hz
Operating range utility frequency(Hz)47-52Hz or 57-62Hz(adjustable)
Max. efficiency96.7%
Euro efficiency96.2%
MPPT efficiency99.9%
DC reverse-polarity protectionYes
AC short circuit protectionYes
AC output overcurrent protectionYes
Output overvoltage protection-varistorYes
Insulation resistance protectionYes
ground fault monitoringYes
Surge protectionYes
Grid monitoringYes
Islanding protectionYes
Temperature protectionYes
integrated DC switchOptional
General Date
Internal consumption<1W(Night)
Running temperature-25℃ ~ 60℃
Ingress protectionIP65
Noise emission(typical)<30 dBA
Cooling conceptatural convection
Max.operating altitude without derating4000m
Designed lifetime>20 years
Utility monitoringEN50438, G83/2, AS4777, VDE0126-1-1, IEC61727
Operating surroundings humidity0~100%
EMCEN61000-6-1:2007; EN61000-6-3:2007 IEC62109-1-2; AS3100
DC ConnectionOriginal MC4 Connector
AC ConnectionIP67 rated plug
DisplayLCD, 2×20 Z.
InterfaceRS 485, WiFi/GPRS(optional )
Warranty5~10 Years



Company Information



Packing & Payment




1.Can I know how to choose the models?

Please read the DATA SHEET in the page or download our products Catalog of each products,Of course it is ok for you, please inquire us directly for any techique questions of our products.

2.If you can accept my own payment ways?

If your order less than 1 KW, Only accept 100%TT or Paypal(and you need to pay the transfer fee);If the order bigger than 1 MW,it is up to you on any payment terms;


3.Are you factory or trading company?

We are a professional factory and manufacturer with more than 10 years(but just open Alibaba Platform 1 year);


4.Where is your factory located?How can I visit there?

Shanghai Hong International Trading Co.,Ltd(trading firm with headquaters in Shanghai)

Add:24F,Block A,No.18 Caoxi North Road,Xuhui District,Shanghai,China.

Jiaxing Osolar PV Co.,Ltd(factory in Zhejiang)

Add:No.1555,Xi Ping Si Road,Pinghu Economic Development Zone,Zhengjiang,China.

Suzhou Solarwii Micro Grid Technology Co.,Ltd(factory in Suzhou)

Add:Rm 405,Nan Gong Yuan Building,No.399 Linquan Street,Suzhou Industrial Park,Suzhou,China.

Changzhou Allstar Energy Technology Co., Ltd(factory in Jiangsu)

Add: Zhiqian Town, Jintan Changzhou, Jiangsu, China.


5.How does your factory do regarding quality control?

Quality is priority.We always attach great importance to quality controlling from the begining to the end(including Solar Cell Testing,Solar Cell Sorting,Automatic String,Electrical Performance Testing),all products are fully approved and certificated by globally recognized authority,including IEC/TUV/CE/C.
